Peplink Balance SDX Pro
Modular SD-WAN Router with Edge Computing Capability
SDX Pro Base Model, No Expansion module, 500GB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
Our Price: Request a Quote
SDX Pro Base Model, No Expansion module, 1TB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
Our Price: Request a Quote
SDX Pro Base Model, No Expansion module, 2TB SSD, 2x GE WAN/LAN Ports, 2x 10GE SFP+ WAN/LAN ports, 2x USB WAN
Our Price: Request a Quote
More pricing below, click here!
Please Note: All Prices are Inclusive of GST
Overview:
Modular SD-WAN Router with Edge Computing Capability
Ready-Built Infrastructure
Your SDX Pro comes ready to connect to the SpeedFusion Cloud: a global network of secure endpoints with unique capabilities. Use the SpeedFusion Cloud as an unbreakable worldwide VPN, saving setup and maintenance costs.
Ready for Anything
Insert a cellular module and a GE or SFP+ module to provide cellular failover for branch networks. Insert a SIM Injector module to dynamically allocate up to 56 SIM cards. New FlexModules are in development, making this device futureproof.
High Throughput
The SDX Pro has enough throughput to handle any high-bandwidth enterprise branch or mobile deployment.
Edge Computing Capable
The SDX Pro is a one-box hosting solution that can deliver Docker containers, applications, and websites to its local network. By hosting resources near the network edge, you can reduce latency and make applications more responsive.
Uninterruptible Power
The SDX Pro is equipped with two power inputs and two hot-swappable power supplies. Only one of each is needed to function, ensuring continuous power delivery even if a cable gets disconnected or if a power supply drops out for any reason.
Specifications:
| Balance SDX Pro | |
|---|---|
| WAN Interface | 2x 10G SFP+ Ports 2x GE Ports 2x USB 2.0 Ports for Secure OOBM 2x FlexModules (Optional)) |
| Router Throughput | 24 Gbps |
| PepVPN / SpeedFusion Throughput | No Encryption: 1 Gbps 256-bit AES: 600 Mbps |
| Recommended Users | 500-2000 |
| Max PepVPN/SpeedFusion Peers | 800 |
| Power Input | AC Input 100V - 240V |
| Power Consumption | 140W System 420W PoE+ Power Budget |
| Number of IPsec Tunnels | 500 |
| 802.1q VLANs Supported | 1024 |
| Drop-In Mode | Yes |
| Recommended PPTP/L2TP/OpenVPN Users | 500 |
| Maximum Number of APs Supported | 2000 |
| High Availability | Yes |
| Dimensions | 17.2 x 13.8 x 1.7 inches / 438 x 350 x 44 mm |
| Weight (Modules) | 80W, 330W PoE+ Power Budget |
| Dimensions | 17.2 x 13.3 x 1.7 inches | 438 x 340 x 44 mm |
| Weight (No Modules) | 15.9 pounds | 7.2 kg |
| Operating Temperature | 32° - 104°F / 0° - 40°C |
| Humidity | 10% - 85% (non-condensing) |
| Certifications | FCC, IC, CE |
| Package Content | SDX Pro Base Chassis 1U 19″ Rack-mount Chassis 1x Rubber Foot Pack 2x Power Cords 1x L-mount Set |
| Warranty | 1-Year Limited Warranty |
Documentation:
Download the Peplink Balance SDX Pro Datasheet (PDF).
